mspa MONO C-MO04 Bedienungsanleitung Seite 19

3. Smooth the surface to remove any air bubbles and allow it dry for 5-10 minutes
NOTE: Glue is not included.
1
Inflatable Valve Sealing Washer Blow-out
For leakage on the valve cover
A. Use wrench to disassemble the valve and check the position.
B. Valve's position deviate:
i. Find out the correct position;
ii. Cut out the extra trim edge;
iii. Put an extra seal ring on top;
iv. Assemble the valve back and charge to recommended air pressure.
C. No deviation:
i. Clean the thread on the surface of the base or inner part.
ii. Assemble the valve back.
iii. Inflate the SPA.
iv. Tighten the valve further and inflate to recommended air pressure.
2
pin hole pin hole
19
3
