ENGLISH
Slave Mode
By choosing the right slave mode you can improve the impact of the multi-channel shows.
The first slave should be in "SL 2" mode, the second in "SL 3" mode, etc. until "SL16".
 Press the MENU button until
 Press the ENTER button to select.
 Use DOWN and UP button to select one of the available slave modes.
 Once the right mode is selected, press the ENTER button to confirm.
 Press the MENU button for about 2 seconds to return to running mode.
Sound Mode
Used to choose the desired sound mode to trigger the shows.
 Press the MENU button until
 Press the ENTER button to select.
 Use DOWN and UP button to select one of the available modes:

(sound mode ON)  the shows are triggered by the internal microphone.

(sound mode OFF)  the shows are triggered by the speed selected with the shows.
 Once the right mode is selected, press the ENTER button to confirm.
 Press the MENU button for about 2 seconds to return to running mode.
Blackout Mode
Blackout mode: when no DMX-signal is detected, the unit goes in blackout.
No blackout mode: when no DMX-signal is detected, the unit automatically switches to master mode.
ALWAYS set to "No Blackout" when the unit is used in standalone or master (master/slave) mode!!!
 Press the MENU button until
 Press the ENTER button.
 Use DOWN and UP button to select YES (blackout) or no (no blackout) mode.
 Once the mode is selected, press the ENTER button to confirm.
 Press the MENU button for about 2 seconds to return to running mode.
Color Preset Mode
Used to choose one of the 16 standard preset colors. You can also define your own custom color,
based on individual settings for red, green and blue.
 Press the MENU button until
 Press the ENTER button to select.
 Use DOWN and UP button to select one of the available options:
 Select one of the preset colors
 Select
to make your own color and press ENTER to confirm. Now you can set the 3 colors to
make your own custom color:

(red): press ENTER. Then use the DOWN and UP buttons to set the value between 000
and 255. Confirm with the ENTER button. Use the DOWN and UP buttons to select the next color.

(green): press ENTER. Then use the DOWN and UP buttons to set the value between 000
and 255. Confirm with the ENTER button. Use the DOWN and UP buttons to select the next color.

(blue): press ENTER. Then use the DOWN and UP buttons to set the value between 000
and 255. Confirm with the ENTER button. Use the DOWN and UP buttons to select the next color.
 Once the right settings are done; press the MENU button for about 2 seconds to return to running mode.
Led Display
Display on: display is always on.
Display off: display is off when not used.
 Press the MENU button until the display shows
 Press the ENTER button.
 Use DOWN and UP buttons to select
 Once the mode is selected, press the ENTER button to confirm.
JB SYSTEMS
®
is shown on the display.
is shown on the display.
is shown on the display.
is shown on the display.
to and press ENTER to confirm.
.
(display always on) or
7/65
OPERATION MANUAL
(display off when not used).
PLANO SPOT 7TC
