05. Press and hold the two Up and Down pushbut-
tons simultaneously until the awning has complet-
ed one short up and down movement, then re -
lease.
06. At this point, activate an up manoeuvre followed
immediately by a down manoeuvre to enable the
Control unit to memorise the two limit positions.
Caution! - Never interrupt these two manoeu-
vres or disconnect power supply during these
movements.
5.4 - Programming limit positions "0" and "1"
SEMI-AUTOMATICALLY
Caution!
- This programming mode is recommended for
awnings with boxes.
- Program first position "0" followed by position "1".
01. Press and hold the pushbutton (Up or Down) to
move the awning to the point of mid-travel. Note -
during movement, 2 brief interruptions indicate
that no limit position is memorised.
02. Press and hold the Up pushbutton until the aw -
ning stops on impact with limit switch "0".
At this point, if the user wishes to leave the
RDC function enabled, release the Up button
and continue the procedure from point 05; oth-
erwise, keep the Up button pressed and at the
same time press Down and continue the pro-
cedure.
03. Wait for the awning to complete a brief down mo -
vement.
04. Release the two Up and Down buttons.
05. Press and hold the Down pushbutton until the
awning moves to the required limit position ("1");
then release the button.
06. Press and hold the two Up and Down pushbuttons
simultaneously until the awning has completed one
short up and down movement, then release.
07. Release the two Up and Down buttons.
5.5 - Personalising the torque value implemen -
ted by the "RDC" function
Caution! - The "RDC" function level can only be
personalised after programming the limit position
values "0" and "1".
01. Press and hold the Up pushbutton until the aw -
ning reaches limit position "0" (do not release the
button).
02. Then press the Down button the same number of
times as the level to be selected (the button must
be pressed for 1 second; then wait 1 second be -
fore pressing it again). With the Up button still
pressed, wait until the awning completes the same
number of movements (in the down direction) as
the new level set. The levels available are:
level 1 = maximum force (*)
level 2 = medium-maximum force
level 3 = medium force
Note – (*) Factory setting.
03. Then release the Up button
5.6 - Programming the "FRT" function
(position "2")
This function is used to tension the awning canvas
when open. The function is activated by programming
position "2" in To-Max T.
During use of the automation, when the awning opens,
the motor moves it first to position "1" and then imme-
diately tensions the canvas by automatically activating
a short up movement to position "2".
Caution! - The "FRT" function level can only be set
after programming the limit position values "0" and
"1".
To activate the "FRT" function:
01. Ensure correct programming of the two limit posi-
tions "0" and "1" by completing a manoeuvre.
02. Use the Down button to move the awning to posi-
tion "1".
03. Press and hold both the Up and Down buttons
until the awning performs a short up movement
and then release the buttons.
04. Use the Up button to close the awning by a few
centimetres, until the canvas can be seen to be
adequately tensioned (this will be position "2").
05. Press and hold both the Up and Down buttons
until the awning performs a short up movement
and then release the buttons.
To deactivate the "FRT" function:
01. Use the Up or Down button to move the awning
to the point of mid-travel.
02. Press and hold both the Up and Down buttons
until the awning performs a short up movement
and then release the buttons.
03. Press and hold the Down button to move the
awning to limit position "1" and release at exactly
the time at which the awning stops at this limit.
04. Press and hold both the Up and Down buttons
until the awning performs a short up movement
and then release the buttons.
Nota – After cancelling position "2" the awning will
move between the limit positions "0" and "1".
5.7 - Programming the "FTC" function
This function enables automatic connection and dis-
connection of the awning. The "FTC" function can only
be activated if the Awning is fitted with an automatic
canvas connect/disconnect device, positioned at the
awning opening position.
In general this type of mechanism has a stop for
mechanical connection of the awning and two addi-
tional points (positioned beyond the stop) which the
awning must reach to enable connection (in position
"1") and disconnection (in position "S") of the canvas.
Therefore to ensure correct operation of this mecha-
nism, the two positions "1" and "S" must be set and
memorised as described below.
CAUTION!
- Before programming the "FTC" function, ensure that
English – 5
