(10) MOWING DECK ELEVATION ADJUSTMENT LEVER
The lever serves to set the elevation height of the mowing deck from the ground.
When travelling without mowing the lever must be set to the transport position!
The mulching function can be improved by using a special accessory, a so-called „mulching
set", which is supplied separately as a special accessory for mowing maintained lawns.

(11) THROTTLE LEVER

Serves to regulate the engine speed. It has the following three positions:
(12) CRUISE CONTROL DISENGAGE LEVER
This lever disengages the mechanical cruise control function and so it is possible to travel with the
machine very accurately at a slow speed.
Do not disengage the cruise control when travelling at a high speed!
The lever has 4 work positions (50 - 60 - 75 – 100 mm), where the
corresponding mowing height is 5 to 10 cm. The higher the number
of the lever position, the higher vegetation height remains after
mowing.
There is also 1 transport position, which is 120 mm above the
ground. When the lever is set to the transport position it is not
possible to activate the mowing deck as a safety switch is built into
this position.
MAX Maximum engine speed
MIN Minimum engine speed (idle)
0 Cruise control is disengaged
1 Cruise control is engaged
28
