5

Service

CAUTION!
To clean the charger, make sure the power plug is disconnected and clean with a dry cloth.
To ensure proper charger function, keep the contacts of the charger and batteries free of dirt.
6

Maintenance

NOTE
If repair is required, send the complete charger to Sales & Service Center. It may be repaired only by autho-
rized technicians. Opening the charger will void the warranty.
7

Technical data

Features
Supply voltage
Power supply frequency
Efficiency factor
Max. supply current
Power loss in standby
Rated battery voltage
End-of-charge voltage
Open circuit voltage, without battery
Charging current
Protection category
Weight without cable
Ambient temperature
Relative humidity
Life expectancy
69b_1_5 en.fm, 16.03.2015
EN EN EN
Data
85 to 270 VAC
50 to 60 Hz ±6%
110 VAC > 90 %
230 VAC > 93 %
110 VAC 1 A
230 VAC 0,5 A
110 VAC 5 W
230 VAC 4 W
44/26 VDC
50.4/29.4 VDC ±1%
Max. 1 VDC
max. 2000 mA ±10%
IP30
0.82 kg (6.8 lbs)
+0°C to +45 °C (+ 32 °F to + 113 °F)
0 to 90 %
60,000 h
P2069BA/INT 2014-06
5
Service
21
