BURG WÄCHTER secuENTRY easy PINCODE Bedienungsanleitung Seite 44

Overview of screws and hexagon adaptors
Fig. on a scale of 1:1
M4x16 M4x20
L = 7 L = 11
Adaptor ( L = length in mm)
8 Insert the CR123A lithium battery with the correct polarity (positive
pole forward).
9 Slide the sleeve onto the outer knob and lock it in place.
10 Remove the battery safety strip on the inner knob.
11 The function test must be made with the door open.
48 | English
M4x25 M4x30
L = 16 L = 21
M4x35 M4x40
L = 26 L = 31
secuENTRY easy
M4x45
L = 36
D
