4.4

Operating level

4.4.1

Beverage mode

4.4.1.1 Beverage mode: initial start-up / reset
Fig. 6: Beverage mode: initial start-up / reset
1 Fill level of mixing container
2 Cleaning intervall reached.
3
key: last cleaning
4 Days until ' Beer-Cut'
5
Activates "Cleaning mode"
6
Activates "Rinsing mode"
Display of "last cleaning"
There are no cleaning protocols at initial start up or reset. In this case, the user can set
the weeks (0-8) since last cleaning.
Fig. 7: Display of last "cleaning"
1.
After pressing "last cleaning" key
2. In field "weeks" the following settings can be done:
0 = cleaning today, 1 = cleaning a week ago, 2 = cleaning two week ago and so on
up to 8 = cleaning was eight weeks ago.
Ä Chapter 4.4.2 'Cleaning mode' on page 23.
Ä Chapter 4.4.3 'Rinsing mode' on page 26.
the display change to "last cleaning".
