Control / Visualisation
4.3

Menu structure

4.3.1

Operating level

The display messages are colour-coded according to the operating mode:
– Beverage mode (green)
– Cleaning mode (yellow)
– Rinsing mode (blue)
– Alarm (red)
The operator therefore knows which operating mode the Cleaning Module is
currently in and whether action is required.
Fig. 5: Menu structure
Rev. 04-06.2018
20
