3. MOUNTING OF THE AMPLIFIER

Before you attempt the installation of your R650FRD 6-chan-
nel amplifier, it is recommended to map out the complete au-
dio system and the respective wiring required. Please note
that - because of possible interference problems with the
existing car electrics and electronics - especially the routing
of the signal cables and the chassis ground connection will
have a profound impact on the performance of the overall sy-
stem. Secondly, the correct mounting location needs your at-
tention too (proper cooling of the amp!). Use only quality in-
stallation material and if you have only little or no experien-
ce with complex car audio installations, we strongly re-
commend you to consult your nearest authorized RODEK
dealer/installer.

3.1 MOUNTING LOCATION

The mounting location should be carefully selected. In the
interest of passive driver and passenger safety, the ampli-
fier must be securely mounted, and special precautions must
be taken to allow sufficient cooling. A clearance of at least
5cm to all sides of the amp must be considered.
Make sure there is no wiring harness, fuel tank etc. behind
or below the mounting surface that may be damaged by the
drilling of the holes for the amplifier mounting screws. The
above mentioned clearance of at least 5cm to all sides of the
amplifier is necessary not only for proper cooling, but also
because the input gain controls must remain accessible.
The amplifier must NOT be mounted directly to the
chassis ground of the vehicle, this may cause ground
loops and the result will be a loud humming noise.
