2. INPUTS – OUTPUTS - CONTROLS
1. RCA inputs ("CH1/CH2", left and right channels). Line
inputs for connection with RCA line-outs of the head-unit
2. RCA inputs ("CH3/CH4", left and right channels). Line
inputs for connection with RCA line-outs of the head-unit
3. RCA inputs ("CH5/CH6", left and right channels). Line
inputs for connection with RCA line-outs of the head-unit
4. Input gain control. LEVEL adjustment for channels "CH1/2".
Used to match the RCA line output voltage of the head-unit
to the amplifier input section
5.Input gain control. LEVEL adjustment for channels "CH3/4".
Used to match the RCA line output voltage of the head-unit
to the amplifier input section
6. Input gain control. LEVEL adjustment for channels "CH5/6".
Used to match the RCA line output voltage of the head-unit
to the amplifier input section
7. Operation LED's, POWER is lit blue when power is on -
PROTECTION LED is lit red when the amplifier is shut down
because of malfunction, overheating or short cut on speaker
cable leads
16
8. "GND" for connection to chassis ground or negative
terminal of car
battery
9."REM" for the automatic (remote) turn-on / turn-off of the
power amplifier from the head-unit's remote or antenna con-
trol lead
10."+12V" for connection to the positive terminal of car bat-
tery
11. Speaker Terminal output block, for connection of loud-
speaker wires
12. Fuses (not show as located on the bottom panel side).
For this amplifier model, only use 25A Mini-ATC fuses!
