Parts of the appliance
1
Overview
Fig. 1:
1 "Carpet/hard floor" switch
2 Suction hose release catch
3 Telescopic tube catch
4 Bypass vent
5 Motor protection filter cover catch
6 Dust container release catch
7 Cable retraction button
8 Parking bracket
9 On/Off switch
10 Exhaust filter cover release catch
Fig. 2:
1 Floor nozzle (standard)
*optional accessories (included in the scope of
delivery depending on model and features):
2* Parquet brush: for vacuuming delicate sur-
faces (e.g. laminate, parquet)
3* Turbo brush: for thoroughly deep cleaning
carpets with the revolving brush head
4* Mini turbo brush: for deep cleaning uphol-
stery with a rotating brush head
ATTENTION:
Our turbo brush serves solely to vacuum
non-sensitive carpets, runners, doormats,
and the like. Do not clean any objects with
the turbo brush that you would not clean
without a second thought with a conventional
brush. Therefore, do not clean furniture, or
materials with a delicate texture, nor any
other high-quality or polished substrates with
the turbo brush. Otherwise material damage
might occur. If in doubt, refrain from using
the turbo brush. In every instance observe
the instructions for care and cleaning of the
respective manufacturer.
Fig. 3:
1 "Carpet/hard floor" switch
- A: for deep- and short-pile carpets, run-
ners
- B: for hard floors, e.g. laminate, tiles,
PVC, etc.
Fig. 4:
1 2-in-1 combi nozzle (loosely in the carton)
(see also Fig. 5)
2 Crevice nozzle (loosely in the carton)
*optional accessories (included in the scope of
delivery depending on model and features):
3* Flexible, long crevice nozzle
NOTE:
When you use the long, flexible crevice noz-
zle, under certain circumstances the pres-
sure inside the vacuum cleaner might drop
too far thus triggering the safety valve. The
signal for this is e.g. a whistling noise
(depending on the vacuum cleaner model)
and greatly reduced suction performance. In
this case, depending on the vacuum cleaner
model and equipment, you have to reduce
the suction power or open the bypass vent
until the valve no longer triggers.
Fig. 5:
The 2-in-1 combi brush can be used as:
1 Furniture brush
2 upholstery nozzle,
you only have to remove the
3 brush attachment
as shown.

Technical data

Type of appli-
: bagless multi-cyclonic
ance
vacuum cleaner
: Infinity VS8 Loop
Model name
Model
: M5035 (-0/-1/.../-8/-9);
M5038 (-0/-1/.../-8/-9)
Voltage
: 220-240 V ~ 50 Hz
Power
: 1.400 W nom - 1.600 W max
Dust container
: approx. 1.5 litres
capacity
Filters
: Dual motor protection filter
(washable), exhaust filter
Power cord
: approx. 6 m
Weight
: approx. 5.5 kg
Technical and design specifications may be changed
in the course of continuous product improvement.
© Royal Appliance International GmbH
1 Overview
Thank you!
Thanks for your purchase of the Infinity VS8
Loop and your confidence in us.
Contents
1
Overview ............................. 13
2
Safety instructions ............ 14
3
Operation ............................ 16
4
Storage ............................... 17
5
Maintenance ....................... 18
6
Troubleshooting ................ 19
