Zircon StudSensor L20 Bedienungsanleitung

GB
StudSensor
Edge-Finding Stud Finder
BEFORE YOU BEGIN
ZIRCON ® STUD FINDERS WORK BY SENSING DENSITY CHANGES BEHIND THE WALL. OTHER OBJECTS CAN BE DETECTED ESPECIALLY
IF THEY ARE VERY CLOSE TO THE WALL. DO NOT ASSUME EVERYTHING DETECTED IS A STUD.
- Always use a new 9V alkaline battery with an extended expiration date at least 3 years beyond the current date.
- Do not rely exclusively on the tool to locate items behind a surface. Use other information to help locate such items before
penetrating the surface, including construction plans, visible points of entry of pipes and wiring into walls such as in a basement,
and standard stud-spacing practices.
- Always scan for studs at several different heights on the wall and mark the location of every target indicated by the stud finder.
This is called "mapping the wall." Pipes and other objects will likely not give consistent readings from floor to ceiling, like a stud will.
- Readings should always be consistent and repeatable.
- Zircon stud finders are recommended for interior use only.
- Studs normally run from floor to ceiling, except above and below windows, and above doors.
- Other objects commonly contained in walls, floors, or ceilings are water pipes, gas lines, firestops, and electrical wiring.
- Sensing depth and accuracy can vary depending on scanning environment conditions such as mineral content, moisture, texture and
consistency of the wall materials.
- Always turn off power when working near electrical wires.
- Depending on the proximity of electrical wiring or pipes to the wall surface, the tool may detect them in the same manner as studs.
Caution should always be used when nailing, cutting, or drilling in walls, floors, and ceilings that may contain these items.
- Studs and joists are normally spaced 40 or 60 cm apart, are normally 38 mm wide, and may be separated by firestops. Anything
closer together, or of a different width, may not be a stud or joist.
TROUBLESHOOTING & CONSTRUCTION TIPS
SITUATION LIKELY CAUSE
No indications. No studs in the area. Move tool 13 – 15 cm to the left or right and start again.
READY Icon shows
Tool may not be flat
but nothing happens Hold tool so that the pads on the back make full contact with the surface.
against wall.
when scanning.
Tool was calibrated over a
Turn tool off, move over 5 – 8 cm, press Power Button, and start again.
stud or on dense part of wall.
Unit beeps repeatedly.
Tool tilted or lifted On rough surfaces, place thin cardboard on wall, scanning over it to help slide tool
during scan. more smoothly.
• Check for other studs equally spaced to either side at 30, 40, or 60 cm intervals,
or check for the same stud at spots directly above or below the first scan area. Studs
Tool detects objects Electrical wiring and metal or
will run straight up and down, from floor to ceiling, while pipes may change direction.
other than studs plastic pipes may be near to
Standard studs measure approximately 38 mm between edges. Anything larger or
or finds more studs or touching the back of the
smaller is likely not a stud (unless near door or window).
than should be there. wall surface.
Use caution when nailing, sawing or drilling into walls, floors and ceilings where
•
these items may exist.
Visit uk.zircon.com for the
most current instructions.
L20
™
INSTALL 9-VOLT BATTERY
Always use a new 9V alkaline battery
with an extended expiration date at
least 3 years beyond the current date.
the tool to locate items behind
SOLUTION
a surface. Use other information
to help locate items before penetrating the surface,
including construction plans, visible points of entry
of pipes and wiring into walls such as in a basement,
and standard stud-spacing practices.
POWER UP
To activate tool, press and hold Power Button. If button
is not held, unit shuts off.
FIND A STUD
The tool is designed to locate the edges of wood and metal studs
up to 19 mm behind the scanned surface.
The accuracy of the position of a stud
found is typically within 3 mm.
For best results, hold the tool as
shown ( Figure A ), and move slowly
when scanning.
Do not touch the surface during
calibration or scan.
1.
then press and hold Power Button.
In 1–2 seconds, the unit will calibrate,
and the Green READY Light will illuminate.
DO NOT MOVE TOOL DURING CALIBRATION.
ZirconCorporation ZirconTV
|
ZirconTools ZirconToolPro ZirconTools
2.
Button, slide the tool slowly along
the wall.
SpotLite ® Pointer
3.
Stud Edge Groove
of the stud, the Red EDGE Light will
illuminate, the SpotLite Pointer will
shine, and a steady tone will sound.
Red EDGE Light
Mark the spot. ( Figure B )
Green READY
4.
Light
continue the scan direction until the
Red EDGE Light and the SpotLite
Pointer turn off, then reverse direction.
5.
of the stud is detected and mark this
as well. (Figure C)
Power Button
The centre of the stud is the midpoint
Ergonomic Grip
between the two marks.
OVER-THE STUD WARNING
If scanning begins directly over a stud, the tool will emit a
Battery Door Tab
continual beep.
(door on bottom)
If this happens, restart the scan in a different location.
THE WALL. DO NOT TAKE ACTIONS THAT COULD
BE DANGEROUS IF THE WALL CONTAINS A LIVE
ELECTRICAL WIRE. ALWAYS TURN OFF THE ELECTRICAL,
GAS, AND WATER SUPPLIES BEFORE PENETRATING A
SURFACE. FAILURE TO FOLLOW THESE INSTRUCTIONS
Do not rely
MAY RESULT IN ELECTRIC SHOCK, FIRE, AND/OR SERIOUS
WARNING
exclusively on
INJURY OR PROPERTY DAMAGE.
WORKING WITH DIFFERENT MATERIALS
Wallpaper This tool functions normally on walls covered with
wallpaper or fabric, unless the materials are metallic foil, contain
metallic fibres, or are still wet after application. Wallpaper may
need to dry for several weeks after application.
Freshly painted walls Paint may take a week or longer to dry
after application.
Lath and plaster Due to irregularities in plaster thickness, this
tool is not recommended for use on lath and plaster.
Hold tool flat against wall,
Figure A
While holding down the Power
When the tool reaches the edge
Figure B
Without releasing Power Button,
Slide the tool until the other edge
Figure C
DO NOT ASSUME THERE ARE NO
WARNING
LIVE ELECTRICAL WIRES IN
LIMITED 2 YEAR WARRANTY
Zircon Corporation, ("Zircon") warrants this
product to be free from defects in materials and
workmanship for two years from the date of
purchase. Any in-warranty defective product returned
to the place of purchase with proof of purchase date
will be replaced at retailer's option. This warranty is
limited to the electronic circuitry and original case of
the product and specifically excludes damage caused
by abuse, unreasonable use or neglect. This warranty
is in lieu of all other warranties, express or implied,
and no other representations or claims of any nature
shall bind or obligate Zircon. Any implied warranties
applicable to this product are limited to the two year
period following its purchase.
Highly textured walls or acoustic ceilings When scanning
a ceiling or wall with an uneven surface, place thin cardboard on
the surface to be scanned.
This tool cannot scan for studs and joists through carpet
and padding.
Electrical wiring and pipes Depending on the proximity
of electrical wiring or pipes to the wall surface, the tool
may detect them in the same manner as studs.
Caution should always be used when nailing, cutting,
or drilling in walls, floors, and ceilings that may contain
these items.
Studs and joists are normally spaced 40 or 60 cm apart, and
are 38 mm wide. Anything closer together, or of a different width,
may not be a stud or joist.
NOTE: Sensing depth and accuracy can vary
depending on scanning environment conditions
such as mineral content, moisture, texture and
consistency of the wall materials.
This tool is not designed for use with:
• Ceramic tile, slate, granite, marble and other rock surfaces
• Carpeting and padding
• Wallpaper with metallic fibres
• Freshly painted walls that are still damp (may take one
week or longer to dry after application)
• Lath and plaster walls
• Foil-covered insulation
• Glass or any other dense material
• Bathroom inserts such as bathtubs and showers
• Surfaces thicker than 19 mm
IN NO EVENT WILL ZIRCON BE LIABLE FOR ANY
SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES
RESULTING FROM POSSESSION, USE OR MALFUNCTION
OF THIS PRODUCT.
uk.zircon.com
info@zircon.com
©2018 Zircon Corporation • P/N 67555 • Rev C 11/18
SpotLite, StudSensor and Zircon are registered
trademarks or trademarks of Zircon Corporation.
