Vortice HRI-E One Betriebsanleitung Seite 88

7 7
bianco / white
verde / green
grigio / grey
7X0.22
blu / blue
giallo / yellow
rosa / pink
rosso / red
7a 7a
bianco / white
verde / green
grigio / grey
7X0.22
blu / blue
giallo / yellow
rosa / pink
rosso / red
8 8
blu / blue
marrone / brown
3x1.5
GV - Y/G
88
remote on/off
2 speed
A
3 speed
GND
2 speed
A
3 speed
GND
N
L
9 9
bianco / white
verde / green
grigio / grey
7X0.22
blu / blue
giallo / yellow
rosa / pink
rosso / red
9a 9a
bianco / white
verde / green
grigio / grey
7X0.22
blu / blue
giallo / yellow
rosa / pink
rosso / red
10 10
blu / blue
marrone / brown
3x1.5
GV - Y/G
remote on/off
manual By-Pass
2 speed
A
3 speed
GND
manual By-Pass
2 speed
A
3 speed
GND
N
L
