Charge Battery; Used Batteries; Self-Propulsion; Working With The Lawnmower - Grizzly ARM 4051 A Originalbetriebsanleitung

D E F G
N O P Q
X Y Z
Switch off the device, pull the igni-
tion key (
blades to come to a stop. There is
a risk of personal injury.
1. To insert the battery (7) into the
device, push the battery along
the guide rail into the device. It
locks into place audibly.
2. To remove the battery (7) from
the device, press the release
button (
and pull the battery out.

Charge battery

Allow a freshly charged battery
(7) to cool down for approx. 15
minutes before inserting it into the
battery charger (11).
1. Remove the battery (7) from the
appliance, as necessary.
2. Insert the battery (7) in the char-
ging compartment of the battery
charger (11). It will audibly snap
in.
3. Plug the battery charger (11)
into a mains outlet. The charg-
ing indicator lights up:
green LED flashes, red LED
lights up: Battery charging
green LED lights up:
Battery is charged
4. When the battery is fully rechar-
ged unplug the battery charger
(11) from the mains.
5. Press the release button (
on the battery (7) and pull the
battery out of the battery char-
ger (11).
H I J
R S T
23) and wait for the
7b) on the battery

Used batteries

• If a fully recharged battery lasts for
considerably shorter operating times,
the battery is used up and needs to be
replaced. Only use an OEM battery
pack replacement available from our
Customer Service.
• Always take heed of the applicable
safety instructions as well as the envi-
ronmental protection regulations and
information (see "Waste Disposal and
Environmental Protection").

Self-propulsion

Self-propulsion is switched on by
pressing the safety switch (19) on
the handle (1) and simultaneously
pulling the drive bracket (18) in the
direction of the handle (1) until it
clicks in. Then release the drive
bracket (18). The forward move-
ment of the self-propulsion ends
when you release the safety switch
(19). In order to stop self-propul-
sion without switching off the mo-
tor, release the safety switch (19)
slightly until the self-propulsion
decouples. Now press the safety
switch back on the handle (1)
again and proceed mowing without
self-propulsion.

Working with the Lawnmower

Regular mowing encourages increased fo-
7b) liation of the grass and kills off weeds at the
same time. Therefore, not only does each
mowing increase the density of the lawn, it
also produces an evenly resilient lawn.
The first cut is to be made in around April,
at a growth height of 70 – 80 mm. In the
main vegetation period, the lawn is to be
mowed at least once a week.
GB
37
