kroeplin AE2105 Bedienungsanleitung Seite 4

Setting the preset value
Action / Key
Signs and symbols:
- Press shortly and release.
- Press until the display changes.
- Switch on.
Activate the PRESET value
(1.25mm)
- Display the PRESET value
- Store the PRESET value
Adjustment of a new PRESET value
(Example: from 0.00mm to 1.25mm)
- Display the PRESET value
- the SET button hold until the "+"
symbol flashes
- After pressing the SET button to
select the desired position (in this
example, press 4 times to get to the
fourth digit from the left)
- Adjust the digit „4"
+ to – 0 – 1–>
>
- Select next decimal
- Adjust the digit „2"
- Select next decimal
- Adjust the digit „5"
-Finish adjustment of the PRESET-
value. (Release the PRESET-key as
soon as „P" flashes.)
- Store the PRESET value
mm/inch - conversion
(before or after PRESET adjustment)
0689-82
Symbol / Key
2..... –> 9.
Seite 4
ON/
OFF
SET
SET
SET
SET
4 x SET
MODE
SET
MODE
SET
MODE
SET
SET
mm/
inch
11.01.2013
Display
