7
DESCRIPTION OF THE FRONT AND BACK
7.1 DESCRIPTION OF THE AIR VENTS
The air vents [A1] and [A3] on the back and side of the appliance must not be obstructed, to
avoid any risk of overheating.
The light source is equipped with an automatic safety device which stops the lighting if the in-
ternal temperature becomes excessive. A pictogram showing the activation of this safety device
will be displayed on the screen [L1].

7.2 MAINS SOCKET

The electrical power supply of the appliance is via a supplied standard IEC power cord.
7.3 MAINS SOCKET - FUSES
The appliance receives its electrical power supply via the mains socket located on the back
[C2], which must be connected to the mains by the supplied power cord. This socket has a fuse
slot and the general power switch [S2]. When replacing a fuse, it is imperative to disconnect
the product from the network and use a fuse of the same type. The T of «T2.5A» means «timed».
Use only fuses T2.5AL - 250V - UL.
7.4 INDICATIONS AND SYMBOLS ON THE BACK
The signs and symbols on the back of the product allow you to identify it in accordance interna-
tional standards IEC 60601-1, IEC 60601-2-18, IEC 60417 and EN 980 (see paragraph 13).

7.5 COMMUNICATION PORT

A communication port [C4] is available for the connection of this light source to the Sopro
camera.
A service port [C5] is for updating the internal software by an authorised Sopro technician.
A1 Back air vent
A2 Connection tip of for Olympus type light cable
A3 Side air vent
C1 Connection tip of for Storz type light cable
C2 Mains socket
C3 Equipotential socket
C4 Connection to the Sopro camera
- 16 -
