2.0- SPECIFICATIONS
2.1- GENERAL CHARACTERISTICS
MAX dp 171/201C
combines quality and reliability with the respect of European safety regulations. The
MAX dp 171/201C are portable inverter generators which allow welding with coated
electrodes (MMA) and with contact start, with infusible electrodes (TIG). Thanks to
the technology with which they are built, these machines are lightweight with
compact dimensions, and have optimum dynamic characteristics for electrode and
for TIG welding.

2.2- ELECTRICAL CHARACTERISTICS

GENERATOR
Supply voltage
Phases
Frequency
Rated current ED 20%
Rated current ED 100%
Rated power ED 20%
Rated power ED 100%
No-load voltage
Arc voltage
Power factor (ED 20%)
Protective fuses
Power cable
Current regulating range
Welding current ED 20%
Welding current ED 100%
Welding cables
Degree of protection
Insulating class
Cooling
Maximum work temperature
Arc force ARC
Arc force CUR
Pulsating frequency
Slope down
Length
Width
Height
Weight
THE DATA REFER TO 40°C AMBIENT
STEL s.r.l. – Via del Progresso n° 59 – 36020
Loc. Castegnero (VICENZA) - ITALY
TEL. +39 444 639525 (central.) – +39 444 639682 (comm.)
FAX +39 444 639641 – E-mail: stel @ stelgroup.it
http: www.stelgroup.it
MAX dp 171-201C
COD. 6910700020
machines are built according to STEL philosophy which
V
-
Hz
A
A
KVA
KVA
V
V
PF
A
mm
mm²
A
A
mm²
IP
°C
%
%
Hz
sec
mm
mm
mm
Kg
TECHNICAL DESCRIPTION
MAX dp 171C
MMA TIG
230 230
1 1
50/60 50/60
34 23
20 14.3
7,5 5.3
4,6 3.3
72 72
20,16-26,4 10.16-26.4
0,7 0,7
16 16
2,5 x 3 2,5 x 3
4 - 160 4 - 160
160 160
110 110
25 25
23 23
H H
AF AF
40 40
0-200% -
0-500% -
0,4-5 0,4-999
- 0,1-10
330 330
135 135
280 280
6,5 6,5
MAX dp 201C
MMA TIG
230 230
1 1
50/60 50/60
43 30
29 21
9 6,9
6 4,35
100 100
20,16-28 10,16-18
0.7 0.7
20 20
4 x 3 4 x 3
4 - 200 4 - 200
200 200
140 140
35 35
23 23
H H
AF AF
40 40
0-200% -
0-500% -
0,4-5 0,4-999
- 0,1-10
345 345
135 135
280 280
6,85 6,85
33
