Product description

6
7
8
9
10
1. Power Switch
2. Safety Catch
3. Height Adjustment Locking Lever
4. Handle
5. Speed Selector
6. Depth Stop Fine-Adjustment Screw
7. Depth Stop
2
1
5
14
13
11 12
8. Depth Stop Locking Knob
9. Depth Set Block
10. Base Plate
11. Spindle Lock Button
12. Collet Nut
13. Hole for Parallel Guide
14. Parallel Guide Locking Knob
