5. Before starting work

Examine the place where the device is to be used
for hidden electrical cables, gas and water pipes
using a pipe finding device.
Before connecting to the mains, ensure care that
the mains voltage corresponds to the details on
the rating plate.
5.1 Fitting and changing tools (Fig. 2)
The device is equipped with a SDS-plus attachment
system.
Clean tools and grease with a thin layer of
machine grease before fitting.
Pull back fastening sleeve (A, Fig. 2) and hold.
Push and rotate the dust-free tool into the tool
holder as far as it will go. The tool will lock auto-
matically.
Check that it has locked by pulling the tool
5.2 Removing SDS-plus tool (Fig. 3)
Pull back fastening sleeve (A), hold and remove tool.
6. Starting work
(Fig. 1)
6.1 Switching ON/OFF
Switching on:
Continuous duty:
Switching off:
6.2 Handle attachment (Fig. 4)
For reasons of safety, only use the hammer drill
with handle attachment.
You will be able to obtain a safe body position when
working by rotating the handle attachment. Loosen
and turn the handle attachment in an aticlockwise
direction. Then tighten the handle attachment.
6.3 Depth stop (Fig. 5)
Loosen the handle attachment and place the straight
part of the depth stop in the hole. Adjust the depth
stop and retighten the handle attachment.
8
06.11.2001 11:29 Uhr
Press the operating switch (3).
Lock the switch (3) with the
locking button (9).
Press the operating switch (3)
briefly and let go.
Seite 8
6.4 Dust collection device (Fig. 6)
Before carrying out hammer-drilling work vertically
overhead pull dust collecting device over the drill bit.
6.5 Hammer stop (Fig. 7)
Your hammer drill is equipped with a hammer stop
facility for smooth drilling.
To deactivate the hammer action, turn the lever
switch (7) clockwise to position (b).
To reactivate the hammer action, the lever switch (7)
has to be reset to position (a).
6.6 Drill stop (Fig. 8)
You can deactivate the drilling action of the hammer
drill when using it for chiselling work.
To do so, turn the lever selector (8) so that the mark
(c) coincides with the arrow (a) on the machine
case.
To reactivate the drilling action, the lever selector (8)
has to be reset so that the mark (b)
with the arrow (a).
Important!
When hammer drilling you will require a low pressu-
re. Too much pressure will place unnecessary load
on the motor. Check the drill bits regularly. Re-shar-
pen or replace blunt drill bits.

7. Maintenance

Remove the mains plug from the socket before
carrying out any work on the device.
Keep your machine clean at all times.
Never use caustic agents to clean the plastic
parts.
At the end of your work, to prevent dust deposits
you should use compressed air (max. 3 bar) to
clean out the ventilation slots .
Check the carbon brushes regularly (dirty or worn
carbon brushes result in excessive sparking and
speed faults).

8. Ordering replacement parts

Please quote the following data when ordering repla-
cement parts:
Type of machine
Article number of the machine
Identification number of the machine
Replacement part number of the part required
coincides
