Parameterization

Parameterization of timer function

In the PARA TIMER submenu the times T 1 and T 2 have to be set for the timer function (see also
chapter "Configuration: Selection as transmitting relays" CONF RELAYS)
Note:
This menu only appears if a relay - relay 1 in the following example - has been
configured as a timer (Configuration level: submenu "CONF RELAYS").
Setting:
Parameterization for further relays configured as timers is made as described above.
(R models)
Submenu "PARA TIMER".
With
enter submenu
"PARA TIMER".
With
set desired time T1.
Setting range: 1...24 hours.
With
accept and go on to "T2/min".
⇐ relay number 1.
With
set desired time T2.
Setting range:
0.5 ... 5.0 minutes,
Step size:
0.5 minutes.
With
accept and go on to next submenu
"PARA RS 485" (RS models) or "PARA PASS"
or to setting of relay no. 2.
121
