11. Care instructions

Only clean the door station with a soft cloth which has been dampened with mild soap. Dry cloth,
aggressive cleaning agents and scrub cleansers may damage the surface.

12. Technical data

Electrical data
Input voltage a+ / b-
Output voltage L / M
Output current L / M
Name plate illumination at LD / M

General data

Installation height of door station
Light sensitivity
Resolution
View angle
Temperature
Humidity
Housing
Dimensions of front (width x height x depth)
IP Code

13. Service

For the warranty applies the legal requirements. The exchange of the device in a service issue shall be
made by an electrician.
CE Notes
This is a Class A device.
Disclaimer of liability
We have checked the conted of the printed material to compliance with the described hardware and software. However deviations
may occur, therefore no liability is assumed regarding complete compliance. The information in this publication is reviewed regularly
and necessary corrections are uncluded in the following editions.
22 – 25 VDC
3 – 4 VDC
Maximum 15 mA
Maximum 2
1.45 to 1.60 m (reference is the camera lens)
0.2 lux (color) and 0.05 lux (black/white)
PAL, 795H x 596V Pixel, 650 TV-Lines
Horizontal 100° und Vertical 80°
-10 °C to +50 °C
20 % to 90 % non-condensing
Plastic housing
135 x 190 to 365 x 4 mm (50 mm with in-wall box)
IP42
~ 27 ~
