6. Opening a mounted door station

Door stations may only be opened using a special
opening tool. Do not use screw drivers or any other
similar tools to open a door station. Never apply force
when opening it. The opening kit may be ordered
separately from SKS Kinkel Elektronik GmbH.
Insert the narrow part of the opening tool all the way
(until the first stop) into the opening located at the
bottom of the front plate as shown in figure 1 on the
left. As shown in figure 2 push the opening device
away from you. The front plate may be lifted about
5mm away from the wall. With your fingers hold on to
the front plate to keep it from sliding back. Then
continue pushing the opening tool all the way in until
the second stop is reached (see picture 3). Again pull
the opening device toward you until you hear a click
sound. Remove the front plate as shown in the picture
on the left.
Remove the front plate as shown in the picture on the
left. How to put it back in is described on the previous
pages.
