9. Inserting or changing name plates
Name plates may be changed from the front. Only the
SKS removal tool (article number 800164) may be
used to change name plates. Do not use any screw
drivers or any similar tools. The removal tool may be
ordered individually from SKS Kinkel Elektronik
GmbH. Stick the removal tool into the slot located on
the right next to the name plate.
Exerting light pressure towards the name plate on the
left, pull the removal tool towards you until the
removed side of the name plate reaches a 20° angle.
To completely open the name name plate pull it all the
way to the right until the stop and then forward
towards yourself. The name plate may be opened up
to an angle of 90°.
