Electronic ballast OFF
The electronic ballasts are completely switched
OFF when no light is being provided by any of
the 3 light groups.
HVAC output
The floating contact works as an HVAC output
and only switches in response to movement or
presence. It is possible to select any chosen
stay-ON time (1-120 minutes) as well as a
switch-ON delay (up to 10 minutes, room
surveillance).
Room surveillance reduces the sensitivity of the
presence switching output. The contact only
closes on detecting a pronounced movement,
signalising with a high degree of certainty that
persons are present.
Nightmatic
Sensor switches ON/OFF in relation to ambient
brightness.
Alarm
The output only switches for approx. 2.5 sec-
onds when at least 3 movements have been
detected within a time slot of 9 seconds.
Pulse mode
Here, the floating contact is used as pulse
output (2 seconds ON, 8 seconds OFF).
OFF
Switches relay clicking OFF.
7� Accessories
Smart Remote EAN 4007841 009151
– Control via smartphone or tablet
– Load appropriate app and connect via
Bluetooth
– Identify the sensors and read parameters
1 DALI addressing
2 Reach / sensitivity
3 Time setting
4 Twilight setting
5 Relay output function
6 Night light
7 Basic brightness
8 Main light level
9 Constant light
10 Operating mode
11 Neighbouring-light function
12 ECO ON
13 DALI slave sensitivity
14 Dimming
8� Operation/maintenance
The infrared sensor can be used for switching
light ON and OFF automatically. The unit is not
suitable for burglar alarm systems as it is not
tamperproof in the manner prescribed for such
systems. The detector lens may be cleaned
with a damp cloth if it becomes dirty (do not
use cleaning agents).
9� Disposal
Electrical and electronic equipment, acces-
sories and packaging must be recycled in an
environmentally compatible manner.
Do not dispose of electrical and
electronic equipment as domestic
waste.
EU countries only:
Under the current European Directive on Waste
Electrical and Electronic Equipment and its
implementation in national law, electrical and
electronic equipment no longer suitable for use
must be collected separately and recycled in
an environmentally compatible manner.
10� Manufacturer's warranty
As purchaser, you are entitled to your statutory
rights against the vendor. If these rights exist
in your country, they are neither curtailed nor
restricted by our Warranty Declaration. We
guarantee that your STEINEL Professional sen-
sor product will remain in perfect condition and
proper working order for a period of 5 years.
We guarantee that this product is free from
material-, manufacturing- and design flaws.
In addition, we guarantee that all electronic
components and cables function in the proper
manner and that all materials used and their
surfaces are without defects.
18
Making Claims
If you wish to make a claim, please send your
product complete and carriage paid with the
original receipt of purchase, which must show
the date of purchase and product designation,
either to your retailer or contact us at
STEINEL (UK) Limited, 25 Manasty Road,
G B
Axis Park, Orton Southgate, Peterborough,
PE2 6UP, for a returns number. For this
1
reason, we recommend that you keep your
Y E A R
receipt of purchase in a safe place until the
warranty period expires. STEINEL shall assume
MANUFACTURER'S
no liability for the costs or risks involved in
WARRANTY
returning a product.
11� Technical specifications
Dimensions Surface-mounted 120 × 120 × 65
Concealed
Voltage 220-240 V (50/60 Hz)
Power consumption max. <0.5 W (without DALI user)
DALI supply current max. 150 mA
DALI communication Addressable, max. 3 groups, Broadcast 64 users
Angle of coverage, reach 360°, 8 × 8 m presence/radial, 20 × 20 m tangential
(mounted at a height of 3 m)
Mounting height 2.5 - 10 m
Time setting 5 s - 60 min
Twilight setting 10 - 1000 lux
Night light OFF, 10-60 min, all night, 10-50% selectable
IP rating / protection class IP 20 / II
Temperature range 0°C to 40°C
For information on making claims under
the terms of the warranty, please go to
www�steinel-professional�de/garantie
If you have a warranty claim or would like to
ask any question regarding your product,
you are welcome to call us at any time on
our Service Hotline 01733 366700.
5
3
Y E A R Y E A R
MANUFACTURER'S MANUFACTURER'S
WARRANTY WARRANTY
120 × 120 × 124
