5. Installation electrical

E1 Disconnect the 12 V and 230 V supply from
the battery and the electricity supply.
Working w ith
installation
disconnecting the electricity supply
may cause danger to your life!
E2 Choose a suitable installation place for the
Basic Station, such as the storage area
under seats close to the battery box. The
installation can be made on the floor or
against the wall. When installing on the wall,
the cable connections must always be at the
bottom. When selecting the place, make sure
that the Basic Station can be conveniently
accessed from the outside, in case you have
to use the cable for the remote control.
Now fix the Basic Station with 4 screws.
For the connection of the Basic Station,
please drill 4 holes, each with a diameter of 6
mm, into the vehicle floor. Make sure that
there are no installations or supporting parts
in or below the floor, in the area of the
drillings. Place the cables through the holes.
Remove the housing lid of the Basic Station
by loosening the 4 Phillips screws.
E3 Now lay the 6 mm² cables of the left and right
drive unit to the Basic Station.
For the installation and fixing of the cables
please use the clamps provided, which are
part of the delivery. As a protection against
sharp edges, please use suitable electrical
insulation sleeves, which are available in
special shops. Mark the cables for the left and
the right drive units. The cable for the left and
the right drive units should be the same
length. Avoid loops. If possible, install the +
and the - cable separately, with a space
between them.
Keep both cable lengths as short as possible.
Now cut the cables to correct length and from
the ends remove approx. 5 mm of the
insulation. Fix the ring connectors by use of
crimping pliers.
Make sure that they are properly fixed!
Mount the cables as shown in the wiring
diagram .
the electrical
without previously
E4 Now lay the 10 mm² cables from the Basic
Station box to the battery. The isolation
switch is to mount into the plus (+) line. The
switch should be accessible from outside. We
recommend you to place it in the battery box
storage compartment. As a protection against
sharp edges, please use electrical installation
sleeves, which you can purchase in special
shops. The distance between battery and
Basic Station should never exceed the length
of the enclosed cables. The shorter the
cables, the better.
Make sure that you never exchange
the Positive (+) and Negative (-) of
the electricity supply!
Make sure that all cables are installed
properly, solidly and without any
friction.
Carefully seal any holes with suitable
sealing material, from the inside and
the outside.
E5 Fix the housing lid of the Basic Station.
Mount the antenna cable in accordance with
the notes on the Basic Station. If the radio
signal reception is poor, then you extend the
antenna to 54 cm. The cable should be taken
outside the vehicle taking care that the aerial
does not come into contact with any metal
parts.
E6 Now connect the 10 mm² cables to the
battery. The electrical installation is now
completed.
