NB: for compatibility reasons, video files exported from the exterior cannot be read on the STEP
6. Picture in the selected file, press to switch to full screen
Slide your finger from right to left to go to the next picture
7. Press to move the files from internal memory to the SD card
8. Press to delete the entire selected directory
9. Files available on the current directory
10. Press to access the next files. Press the red cross to delete individually.
11. Back to the home page
e. Use of the RFID (for STEP Access only)
Adding one or more user badges:
1. Pass badge , a long beep indicates the switch to programming mode
2 Pass all the user badges to be activated, a short beep indicates the programming for each presented badge.
3. When all the badges have been programmed, wait for 10 seconds. A long beep indicates the end of the pro-
gramming process.
Deleting one or more user badges:
1. Pass badge , a long beep indicates the switch to programming mode
2 Pass all the user badges to be deactivated, a short beep indicates the de-programming for each presented
badge.
3. When all the badges have been deactivated, wait for 10 seconds. A long beep indicates the end of the program-
ming process.
Deleting all the user badges:
1. Pass administrator badge
2 Pass 1 user badge
f. Access function (for STEP Access only)
To open your electric latch or your portal, place a previously programmed user badge on the RFID reading zone for
1 second (outdoor station name holder (fig.3-11). A short beep indicates the opening of the electric latch or gate.
GB9
9
6
8
10
, a short beep indicates the switch to administration mode
, a short beep indicates that all the user badges have been de-programmed.
