3.1.

Location of controls and instruments

Instruments and warning lights (§3.7.)
Rearview mirror (§5.1.)
Clutch lever (§5.1.)
3
Left handlebar electrical controls (§3.3.)
Ignition switch and steering lock (§3.5.)
Fuel tank cap (§4.5.)
Gear lever (§3.6. and §5.1.)
Sidestand (§3.2.)

CONTROLS AND INSTRUMENTS

Left side
Right handlebar electrical controls (§3.4.)
Right side
- 14 -
3
Rearview mirror (§5.1.)
Front brake lever (§5.1.)
Throttle twist grip (§3.4.)
Rear brake lever (§5.1.)
