MACHEREY-NAGEL QUANTOFIX Relax Handbuch Seite 72

A progress bar appears showing the remaining reaction time. After a few sec-
onds, the test strip is drawn into the instrument's housing. After the measure-
ment, the slide moves out of the housing again and the result is displayed in
the screen. The measured test strip can be discarded into the domestic waste.
Note: The reaction time is dependant on the test and programmed into the
instrument. Therefore, different tests have different waiting times. In general
though, the time to wait is hardly ever longer than 60 seconds.
Note: If the autostart function is disabled, you have to start a measurement
pressing (see 13.5 Autostart, p. 85).
MN Manual QUANTOFIX
Manual QUANTOFIX
RESULT
Seq.No: 0001
ID:
2011.08.20 9:47
ASC
128
mg/L
Display 2: Result
Relax EN V 1.10 / 01.14
®
Relax
®
71
