5. Initial operation

This chapter contains a description of the steps necessary to start-up the instru-
ment.
1 Touch screen

5.1 Power connection

The shipment includes four adaptors to connect the power pack to different
outlets. Clip the respective adaptor to the power pack. Once the power cord is
connected to the "DC IN" port (7) and connected to an outlet, the QUANTOFIX
Relax is connected to the power supply.
4 RS232 interface
7 Power connection
60
Relax
®
3
1
Pic. 3: Instrument front
2 Measurement slide
8
4 5
Pic. 4: Instrument back
5 USB interface
8 On / Off switch
Manual QUANTOFIX
2
3 Printer
6 7
6 PS/2 port
Relax EN V 1.20 / 01.14
®
®
