- Service socket (pos. 4)
Connection for KEMPER service. Using this interface, KEMPER service can
make adjustments to the device.
- Horn (pos. 5)
The safe collection of welding fumes is only possible with sufficient suction
power. Should this power drop below the minimum value, the horn sounds and
the yellow LED indicator lamp begins to flash at regular intervals.
The same occurs when the control valve in the extraction nozzle is closed too
tightly, which also significantly reduces the suction power. This can be
corrected by opening the control valve.
- Pressure measurement opening (pos. 6)
Connection for KEMPER service. Using this interface, KEMPER service can
perform pressure measurements.
- Pressure switch (pos. 7 a 8)
Intended only for KEMPER service.
- Connection socket for the Start/Stop sensor (pos. 9)
You can connect an optional accessory Start/Stop sensor.
Its use ensures MaxiFil Clean will only operate during the actual welding
period (for the duration the arc is present) and specified deceleration time.
MaxiFil Clean automatically recognizes the presence of the Start/Stop sensor.
NOTE
The first time you connect the MaxiFil Clean device to the power
supply, a self-test is run, during which the horn briefly sounds and
indicator lamps light up for a short period. The user should perform this
test on a regular basis (weekly) by pulling and reinserting the plug. If
this does not activate the horn and indicator lamps, the MaxiFil Clean
device must be inspected by KEMPER service.
