SIMPLE LOGGER II
1. Inputs 'depends on model)
L101/L102 :
L261/L111 :
L322/L432 :
L562 :
L642 :
2. Five LED indicators
The indicators have two distinct information functions: choice of command to be executed or active function
in progress.
The command to be executed (reached by pressing the "PRESS" button until the desired command appears)
is indicated to the left of the indicator.
The active function or current status (obtained by a brief press on the "PRESS" button) is indicated to the
right of the indicator.
Section 4.1 describes each of the indicators in detail.
3. Command button (« PRESS »)
The button marked "PRESS" is used to choose the operating mode: start or stop recording, erase the
memory, clear alarms, start or stop the device.
4. Mini B female USB connector
This connector, on the base of the device, is used for connection to a desktop computer.
5. « RESET » button(not shown)
The "RESET" button is used to reset the processor. This button is reached by opening the housing: remove
the battery compartment cover and unscrew the four housing closing screws; the button is located on the
LED indicators side of the circuit, near the inputs.
6. "Flash Upgrade" switches (not shown)
These two switches, placed near the "RESET" button, are used to take control of the device if an upgrade of
the internal operating program fails.
WARNING: if the "RESET" button is actuated while recording is in progress, recording will be
interrupted and the data in memory may be lost.
1 BNC connector or 2 BNC connectors.
2 4mm safety banana jacks.
1 removable 4-position screw-type terminal block.
1 BNC connector and 2 4mm safety banana jacks.
2 special miniature thermocouple connectors.
