ENGLISH
MASTER / SLAVE MODE
1. Fix the laser units in a safe way and adjust the suitable angle.
2. Connect the inputs/outputs of the units, using a balanced signal cable.
3. Set the MASTER / SLAVE switch of the first unit (this is the unit where input
connector is free) to "MASTER", the other units are switched to "SLAVE"
4. Connect the units to the 220V AC mains, using the supplied power-cords.
5. Put on some music and adjust the music input level of the MASTER unit.

MAINTENANCE

The unit should be cleaned regularly using a sponge, dipped with alcohol rather than
a wet cloth or other chemical liquid, to clean the mirrors in the front of the Stealth
laser.
BE VERY CAREFUL:
• DISCONNECT THE POWER CORD BEFORE CLEANING OR REPAIR!
• THE MIRRORS ARE VERY FRAGILE, CLEAN THEM VERY GENTLY!
• ONE MORE TIME: DON'T LOOK DIRECTLY INTO THE LASERBEAM!

SPECIFICATIONS

Power Supply:
Power Consumption:
Light source:
Size:
Weight:
Fuse:
AND LOOK FOR OTHER PRODUCTS FROM JB SYSTEMS
JB SYSTEMS
AC 230 V, 50Hz
30W
Green laser 30mW / 532nm (Class 3B)
34 x 30.5 x 16cm
4.2kg
250V ~ 2A slow (ø 5x20mm)
SURF TO:
WWW.BEGLEC.COM
4/16
OPERATION MANUAL
STEALTH LASER
