Intended use
This product is only suitable for transporting with a max weight of 150 kg. Only for private use.
Not for commercial use.
Packaging contents
•
2 Fixed castors
•
2 Swivel castors with brake
•
16 Screws
3
•
16 Locking nuts
5
•
16 Sleeves
•
2 Assembly wrench
•
1 Aluminium foldable trolley
Safety Advice
•
Warning! Please read the instructions before use!
•
Please keep the instructions in a safe place!
•
Keep out of the reach of children. This is not a toy!
•
Check the foldable trolley to see if it is functioning correctly every time before using it. If you detect any damage, the
trolley may no longer be used.
•
Never transport a load weighing more than 150 kg on the trolley.
•
Only use the trolley on smooth, level surfaces, not on staircases or on slopes.
•
Always secure the loading area with the securing clamp to prevent unintended opening or closing.
•
Prior to use, pull out the handle far enough for it to lock into the end position. Otherwise it could retract when
subjected to load.
Assembly Instructions
Fix the four castors with the help of the assembly wrench as demonstrated in fig. D.
After assembly, ensure that all screws have been securely tightened.
Operation
1.
Draw the holder upwards into a vertical position (see fig. B).
2.
Loosen the handle by pressing the metal frame downwards (see fig. C) and pull out the handle until you
hear it lock into position.
3.
Raise the securing clamp and turn it approx. 90° in a clockwise direction until it is resting on the black
cross brace (see engaging images 1, 2 and 3 in fig. D). Now pull the loading area apart until the two black
cross braces meet. Turn the securing clamp another 90° until it overlaps the two black cross braces then
press downwards until it locks into place.
4.
The foldable trolley can be stabilised with the help of the brakes on the two swivel castors. To achieve this,
press the locking lever (see locking image to right in fig. D) downwards against the castors.
5.
To fold up the trolley again, repeat the steps described above in reverse sequences. You must press the
metal frame (see fig. C) downwards to push the handle into its holder and then fold the handle holder.
Cleaning And Care
For cleaning and care, use only a damp, fluff-free cloth.
Maintenance
Check all connection points on the foldable trolley regularly. If you detect any damage, the trolley may no longer
be used.
Disposal
Please dispose of this item in accordance with local waste disposal regulations.
73212_GB_IE_.indd 1
Aluminium Flat Bed Trolley
1
2
4
6
7
3/23/2012 6:29:53 PM
