LIST OF PARAMETERS TO BE DISPLAYED (FUNCTION 3)
Option recognition table
Decimal Hexa.
address address
256 100
257 101
258 102
259 103
NB: if several options are used, the number corres-
ponding to the option must be added.
LIST OF PARAMETERS TO BE DISPLAYED OR PROGRAMMED (FUNCTIONS 3, 6 AND 16)
Decimal Hexa.
address address
512 200
513 201
514 202
515...518 203...206
519 207
520 208
521 209
SOCOMEC - Réf. : 876 581 B
Number Text
of words
1 0 : no option
1 : metering option
2 : communication option
/ Reserved manufacturer
1 option slot 1
0xFF : no option
0x0 : metering option
0x1 :communication option
1 option slot 2
0xFF : no option
0x0 : metering option
0x1 : communication option
Example : metering + communication will correspond
at number 3, that's to say 1 + 2.
Number Text
of words
1 Network type :
0 : 1BL
1 : 2BL
2 : 3BL
3 : 3NBL
4 : 4BL
5 : 4NBL
1 CT secondary :
5 : 5A
1 CT primary
Reserved manufacturer
1
Synchronisation of I MAX :
2 : 2 sec
5 : 5 minutes
8 : 8 minutes
10 : 10 minutes
15 : 15 minutes
20 : 20 minutes
30 : 30 minutes
60 : 60 minutes
1
Synchronisation of P MAX :
2 : 2 sec
5 : 5 minutes
8 : 8 minutes
10 : 10 minutes
15 : 15 minutes
20 : 20 minutes
30 : 30 minutes
60 : 60 minutes
1 OUT allocation :
0 : kWh +
1 : kvarh +
DIRIS A20 - RS485 - JBUS/MODBUS DIRIS A20 - RS485 - JBUS/MODBUS
COMMUNICATION
Unit
/
/
/
Unit
/
A
A
/
/
/
® ®
