Version 11/12
WL-01 Wake-Up Light Radio Alarm Clock
Item no. 35 19 15
1. Intended use
The product serves as an alarm clock and as a radio. It can also be used as a lamp for illumination of indoor
areas. The brightness and volume of the alarm slowly increase, allowing you to awake naturally from your
sleep. Select radio, beeping or seven natural sounds as alarm sounds. There is also a sleep-timer function
which reduces brightness and volume, providing a smooth transition into the sleep phase.
This product is approved for connection to 230 V/AC, 50 Hz alternating voltage only. It is intended for
indoor use only. Do not use it outdoors. Contact with moisture, e.g. in bathrooms, must be avoided under all
circumstances.
For safety and approval purposes (CE), you must not rebuild and/or modify this product. If you use the product
for purposes other than those described above, the product may be damaged. In addition, improper use can
cause hazards such as short circuiting, fire, electric shock etc. Read the instructions carefully and keep them.
Make this product available to third parties only together with its operating instructions.
2. Delivery content
• Wake-Up Light Radio Alarm Clock
• Operating instructions
3. Safety instructions
Read the operating instructions carefully and especially observe the safety information.
If you do not follow the safety instructions and information on proper handling in this
manual, we assume no liability for any resulting personal injury or damage to property.
Such cases will invalidate the warranty/guarantee.
Persons / Product
• The device was constructed according to protection class II. Only a proper mains socket (230 V/AC, 50 Hz)
of the public supply net must be used as voltage source.
• In order to completely separate the device from the mains, the mains plug must be pulled out of the power
socket. Make sure that the mains plug is always accessible and reachable.
• Never pull the mains plug from the socket by pulling at the cable. Always pull it from the mains socket using
the intended grips.
• Unplug the mains plug from the mains socket if you do not use the device for an extended period of time.
• Disconnect the mains plug from the mains socket in thunderstorms for reasons of safety.
• Make sure that the mains cable is not squeezed, bent, damaged by sharp edges or put under mechanical
stress. Avoid excessive thermal stress on the mains cable from extreme heat or cold. Do not modify the
mains cable. Otherwise the mains cable may be damaged. A damaged mains cable can cause a deadly
electric shock.
• Do not touch the mains cable if it is damaged. First, power down the respective mains socket (e.g. via the
respective circuit breaker) and then carefully pull the mains plug from the mains socket. Never use the
product if the mains cable is damaged.
• A damaged mains cable may only be replaced by the manufacturer, a workshop commissioned by the
manufacturer or a similarly qualified person, so as to prevent any danger.
• Never plug in or unplug the mains plug when your hands are wet.
• Never pour any liquids over electrical devices or put objects filled with liquid right next to the device. If liquid
or an object enters the interior of the device nevertheless, first power down the respective socket (e.g.
switch off circuit breaker) and then pull the mains plug from the mains socket. Do not operate the product
anymore afterwards, but take it to a specialist workshop.
• Make sure the device is sufficiently ventilated when in operation. Never cover the device with magazines,
curtains, etc. Never place the device on a soft surface such as, for example, a carpet or a bed, etc. This can
prevent dissipation of heat from the device and may lead to overheating.
• Do not place open flames, such as burning candles, on or close to the device.
• Do not listen to excessively loud music over an extended period of time. This may damage your hearing.
• The device is not a toy. Keep it out of the reach of children and pets.
• Do not leave packaging material lying around carelessly. These may become dangerous playing material
for children.
• Protect the product from extreme temperatures, direct sunlight, strong jolts, high humidity, moisture,
flammable gases, vapours and solvents.
• Do not place the product under any mechanical stress.
• Please handle the product carefully. Jolts, impacts or a fall even from a low height can damage the product.
(Rechargeable) batteries
• Correct polarity must be observed while inserting the (rechargeable) batteries.
• (Rechargeable) batteries should be removed from the device if it is not used for a long period of time to
avoid damage through leaking. Leaking or damaged (rechargeable) batteries might cause acid burns when
in contact with skin, therefore use suitable protective gloves to handle corrupted (rechargeable) batteries.
• (Rechargeable) batteries must be kept out of reach of children. Do not leave (rechargeable) batteries lying
around, as there is risk, that children or pets swallow them.
• All (rechargeable) batteries should be replaced at the same time. Mixing old and new (rechargeable)
batteries in the device can lead to (rechargeable) battery leakage and device damage.
• (Rechargeable) batteries must not be dismantled, short-circuited or thrown into fire. Never recharge non-
rechargeable batteries. There is a risk of explosion!
Miscellaneous
• Consult an expert when in doubt about operation, safety or connection of the device.
• Maintenance, modifications and repairs are to be performed exclusively by an expert or at a qualified shop.
• If you have questions which remain unanswered by these operating instructions, contact our technical
support service or other technical personnel.
4. Operating elements and display description
1
2
MODE SET
UP VOL +
3
DOWN VOL -
4
LAMP NATURE
5
6 7 8 9 10
1 MODE button 9 VOL – button
2 UP button 10 VOL + button
3 DOWN button 11 ON/OFF/SNOOZE switch
4 LAMP button 12 Brightness control
5 RESET button 13 SET button
6 Battery compartment 14 Volume display
7 LC display 15 Radio symbol
8 NATURE button
16 Alarm symbol

5. Operation

Inserting the batteries
The batteries provide the power supply if there is a power outage. Your settings (e.g., time, alarm
time, etc.) are retained.
No batteries are required for normal operation.
Also read the safety instructions on how to handle batteries (see section "3. Safety instructions").
1. Open the battery compartment (6) on the bottom of the device and insert two
type AAA batteries (not included).
2. Observe the correct polarity (+/-) according to the labelling.
3. Close the battery compartment. Make sure that the cover clicks properly into
place.
4. Replace the batteries when they run out.
Setting up and mains connection
1. Place the product on a level, stable and dry surface. When setting it up, ensure that there is sufficient
ventilation and maintain sufficient distance from sources of heat.
Due to the great variety of furniture varnishes and polishes, the device's feet might leave visible
marks on the furniture caused by chemical reactions. Therefore, the device should not be placed
on valuable furniture surfaces without suitable protection.
2. Make sure that the power cable is not pinched or damaged by sharp edges. Always lay the cables so that
people cannot trip over them or become entangled in them. Risk of injury!
3. Make sure that the mains voltage agrees with the indications on the type plate of the product.
4. Connect the mains plug of the mains cable to a proper power socket (230 V/AC, 50 Hz). The LC display (7)
lights up.
Display lighting
To switch the display lighting on/off, press the LAMP button (4) and hold it down for a few seconds.
Switching the lamp on/off
Switch the lamp on or off with the LAMP button (4). Set the desired brightness with the brightness control (12).
Time display
1. Press the UP button (2) to switch between the 12-hour display and the 24-hour display.
2. If you choose the 12-hour display, "AM" for morning and "PM" for afternoon will also be shown in the LC
display (7).
Setting the volume
Press the VOL + (10) / VOL – button (9) to increase/decrease the volume.
You can only set the volume if the radio is switched on or if a natural sound is played.
Radio
1. Switch the radio on or off with the MODE button (1).
2. To store a radio station, first select the storage location number (CH 1 to CH 30) with the UP (2) / DOWN (3)
button. There are 30 storage locations available.
3. Press the SET button (13). The radio frequency starts to flash.
4. To manually search for a radio station, press the UP (2) / DOWN (3) button until you find the desired station.
The radio frequency can be set in 0.1 MHz steps. Alternatively, you can hold the UP (2) / DOWN (3) button
down to automatically search for the next station that can be received.
5. To store the station, press the SET button (13) again.
6. Store other stations in the same way.
7. Press the UP (2) / DOWN (3) button to call up the stored stations.
13
12
11
14 15 16 17
17 Natural sound symbol
18 Sleep display
19 SNOOZE display
20 Brightness display
Not shown:
Mains cable with mains plug
FM antenna
18 19 20
