The following K-type thermocouple sensors can be used with
thermometers C.A 861 and C.A 863.
Sensors with grips and extendible spiral leads
Model
SK 11 Needle P03.6529.17 -50...+600°C
For penetration of viscous thick substances.
SK 13 P03.6529.18 -50...+1100°C
General purpose
All uses
SK 14 P03.6529.19 -50...+450°C
Curved surface
For temperature measurement of poorly accessible surfaces. End Ø 15 x 30 mm
SK 15 Surface P03.6529.20 -50...+900°C
8 mm Ø spring-loaded end, ensuring optimum contact even when the
sensor is not perpendicular to the surface.
SK 17 Air P03.6529.21 -50...+600°C
For measurement of ambient air temperature. Thermocouple is protected
by a 8.5 mm Ø metal shield
PK 9 P03.6529.15 -20...+250°C
Retractable needle
Designed for automobile pneumatics. Penetrates by up to 15 mm.
SK 1 Needle P03.6529.01 -50...+800°C
For penetration of viscous, thick substances.
SK 2 P03.6529.02 -50...+1000°C
Bendable
Bendable as required for application.
SK 3 P03.6529.03 -50...+1000°C
Semi-rigid
Slightly bendable.
SK 4 Surface P03.6529.04
Suited to measurement on small surface areas.
SK 5 Surface P03.6529.05 -50...+500°C
8 mm Ø spring loaded end, ensuring optimum contact even when the
sensor is not perpendicular to the surface.
*
to be used between 0 and 50°C

5. SENSORS

Reference Measurement Response Dimensions
Sensors without grips *
0...+250°C
13
range time
12 s
12 s
8 s
2.3 s
2.6 s
5 s
1 s
2 s
6 s
1 s
1 s
(mm)
Ø 3 - L = 130
Ø 3 - L = 300
Ø 6 - L = 130
Ø 8 - L = 130
Ø 6 - L = 130
Ø 1 - L = 55
Ø 3 - L = 150
Ø 2 - L = 1000
Ø 4 - L = 500
Ø 5 - L = 150
Ø 5 - L = 150
