"Temperature adjuster" (2)
With the "Temperature adjuster" (2) you can select the desired temperature switch-
ing threshold.
The temperature range can be adjusted from +5° to +30°C.

6. Function/Explanation

This thermostat is based on a temperature-controlled threshold value circuit. Power
is supplied by way of a 230 V/AC 50 Hz wall outlet The consumer to be switched
(heating or air conditioning system, max. 6 Ampere) is connected to the relay out-
puts (internal screw terminal available).
With the "Temperature adjuster" (2) you can set the desired room temperature from
+5° to +30°C.
The room thermostat can be used during the winter (in connection with a heater) as
well as during the summer (in connection with an air conditioner) .

7. Installation and connection

When selecting the position for installing your room thermostat,
please note that it must not be subjected to direct sunlight, vibra-
tions, dust, heat or cold. The product is approved only for opera-
tion in dry rooms.
No devices which make strong or electric fields, such as mobile
phones, electric motors, etc. must be in the immediate vicinity.
The connection cables must not be kinked or squeezed. This
can result in malfunctions, short circuits and defects in the
device.
21
