Inserting batteries:

Open the battery compartment (15) on the rear of the DigiLevel and
insert two new batteries (type AAA/LR03) in the manner indicated
by the installation symbols. Ensure correct polarity. The symbol (10)
indicates the level of battery charge.
Switching on and measuring:
The DigiLevel can measure angles continuously to 360°.
• Switch the DigiLevel on using the on/off switch (2).
• The current operating temperature in °C is shown for a few seconds.
• The slope angle is shown in the display (8). If slopes are measured
overhead, the direction of display adjusts automatically.
• The current slope direction is also shown by the symbol (7).
Selection of unit of measurement:
• Button (5) allows the desired unit of measurement to be selected
(° degrees, %, IN/FT)
Acoustic signal:
• The acoustic signal can be switched on or off with button (3).
• When the angle of slope stands at 0°, 45°, 90° or the most recently
stored value, this is indicated by an acoustic signal.
NOTE: When working with a changed angle reference value,
the acoustic signal is activated on reaching the new reference value
(0°, 45°, 90° display).
Changing the angle reference value:
• With button (1), it is possible to transfer angles elsewhere. To do so,
set the device to the desired slope and press button (1). The display
will then change to "0.0", and the desired reference angle is now set.
The slope can now be transferred to other objects.
IMPORTANT: When all the slopes have been transferred, make sure
to deactivate the new angle reference value. To do this, switch off
the device by pressing the on/off switch (2) for at least 3 secs. Only
then will the value be reset itself to the measuring surface (14).
