Flash
Seitenflosse / Vertical stabilizer
Using a modeling knife, remove the covering on the slot
of the vertical stabilizer. Mix up a generous amount of
30 minute epoxy. Apply a thin layer to the slot in the
vertical stabilizer. Slide the vertical stabilize into the
mounting platform of the horizontal stabilize. Using a
triangle, check to ensure that the vertical stabilizer is
aligned 90 degree to the horizontal.
o
90
C/A glue.
Empfänger, Regler und Akku
Receiver, ESC And Battery
Regler ESC
1. A/B Epoxy glue
Receiver
Akku Battery
Tragflächen / Main Wings
Attach
the wing
into the fuselage.
in position.
Open and close
Spinner
Install the spinner backplate, propeller and spinner
cone. The spinner cone is held in place using two
3mm x 15 mm machine screws.
Screw the wing panel
Secure
7
