95% ALMOST READY TO FLY
910mm
750mm
21.7dm
53g/dm
950 ... 1150g
3 Kanal
3
250 ... 650W
40 ... 50A
2200 ... 3500mAh
2
2
Wingspan
910mm
Length
750mm
Wing area
21.7dm
Wing loading
53g/dm
Flying Weight
950 ... 1150g
R/C
3 channels
Servos
3
Motor
250 ... 650W
ESC
40 ... 50A
Battery
2200 ... 3500mAh
2
2
