User manual – Basic seat unit
Backrest upholstery
The backrest upholstery is attached at the top of the back plate, as is the hook and loop strip on the back plate (Fig. 9).
The lower part of the backrest upholstery is inserted to the rear between the seat and the back (Fig. 10). The lower end
is provided with hook and loop and is attached to the rear end of the seat plate to close the gap between the seat and
the back (Fig. 11).
Side cushion
Place each of the shorter cushions of the two side cushion pairs over the side tubes so that the hook and loop is facing
inward (Fig. 12). The hook and loop fastener is located on the outside of the back plate curve. Attach the cushion in
such a manner that the upper edge of the cushion on the back ends just below the thumbscrew (Fig. 13). Then attach
the rear of the cushion with hook and loop (Fig. 14). The zippers of the shorter side cushion can be positioned inwards
if necessary.
Hook and loop each of the longer cushions to the inside of the back plate curve. The longer cushions are attached at a
height where they are flush with the top end of the outer side cushions (Fig. 15).
Lateral seat upholstery
The lateral seat upholstery can be opened with a zipper. It is pulled over the seat side guides in such a manner that the
reflective strip on the outside runs from the rear / top to the front / bottom (Fig. 16).
Holders for sun and rain cover without leg blanket
The Basic comes with holders for the sun and rain cover (without leg blanket) as standard (Fig. 17). Their height can be
adjusted as required. To do so, loosen the screws of the holders for the sun and rain cover and move it on the tubes into
the desired position. Then tighten the screws firmly again.

Possible settings

Seat width
To adjust the seat width, loosen the four soft-touch nuts under the seat of the Basic and move the side elements ac-
cordingly (Fig. 18). Then retighten the nuts. If the seat depth is set to the minimum depth, the maximum adjustable seat
width depends on the gap before the lateral seat upholstery of the back.
Seat depth
Loosen the two front soft-touch nuts under the seat of the Basic and pull the seat plate forwards (Fig. 18). Then retighten
the nuts.
TIP: To easily adjust the seat depth, use one hand to grip the front edge of the seat and use the other to hold the lower
end of the back (in the center) steady. The depth of the seat side guide can also be adjusted. To do so, open the cush-
ions of the seat side guides with the zippers and remove them. Loosen the two screws, set the desired depth and retight-
en the screws (Fig. 19).
Back height
Loosen the two thumbscrews on the side tubes (Fig. 20). Now the height of the backrest can be infinitely adjusted up
to the engagement point (spring pins engage with a click). To reduce the back height, press the spring pins below the
thumbscrews and slide the back plate downwards to the desired height (Fig. 21).
To achieve the maximum back height, also loosen both thumbscrews on the upper cross bar and pull the back plate
upwards (Fig. 22). Then retighten all the thumbscrews.
TIP: The extended tubular bar provides additional safety for children who are predominantly transported in the horizon-
tal position.
