10 | English
charged, the glue gun is switched off by a protective circuit:
The glue is no longer heated.
Battery Charge Indicator
red green Meaning

– The battery is being charged

– The battery is fully charged
The battery has less than 30%

– of its capacity and should be
charged

The battery is completely dis-
–
charged
 Flashing  Continuous light
– Plug the mains plug of the battery charger into the socket
outlet and the charger plug 9 into socket 10.
Disconnect the battery charger from the mains supply when
not using it for longer periods.
 Protect the battery charger against moisture!
Observe the notes for disposal.
Operation

Starting Operation

Switching On
– To start the operation, press the On/Off button 7 until the
heating indicator 6 lights up green.
Heating indicator
green
Meaning

for approx. The glue is being heated
15 s

The glue gun is ready for operation
 Flashing  Continuous light
Switching Off
– To switch off, press the On/Off button 7 until the heating
indicator 6 goes out.
Automatic shut-off:
Note: When the glue gun is not used for more than 5 minutes,
it automatically shuts off.
– Switch the glue gun on again and check the battery charge-
control indicator 8.
When the battery charge-control indicator briefly lights up
red, the battery must be recharged.
 After use, place down the glue gun in a safe manner and
allow it to cool down completely before packing it
away. The hot nozzle can cause damage and/or burns.
1 619 929 K84 | (22.11.12)

Working Advice

 Do not allow the hot glue or the nozzle tip to come into
contact with persons or animals. Glue and nozzle tip
reach a temperature of approx. 170 °C; danger of burning.
If hot glue comes into contact with the skin, hold the affect-
ed area immediately under a stream of cold water for sev-
eral minutes. Do not try to remove the glue from the skin.
Use only glues recommended by the manufacturer of the glue
gun (see page 3).
Bonded connections can loosen under the effect of moisture.
Preparations for Gluing
The surfaces to be glued must be clean, dry and free of
grease.
The materials to be glued as well as the surface on which you
are working may not be easily ignitable or inflammable.
Check the suitability of heat-sensitive materials first on a test
workpiece.
The ambient temperature and the workpieces to be glued may
not be colder than +5 °C and warmer than +50 °C.
Materials, such as metal, which cool off the glue quickly,
should be preheated with a hot air gun.
Gluing
– Insert the appropriate glue stick 4 for the material being
glued via the opening at the rear of the glue gun.
– Switch the glue gun on and allow it to heat up (see "Switch-
ing On", page 10).
The glue gun is ready for operation after approx. 15 sec-
onds.
– Press the feed trigger 3 applying moderate pressure.
– Apply the glue only on one side (also see "Practical Ad-
vice", page 10).
– After applying the glue, immediately press the surfaces to
be glued together. Correcting the gluing location is still
possible at this point.
The glued spot can be subjected to load after a cool-down
period of approx. 2 minutes.

Practical Advice

Material/Workpiece Recommendation
Large-surfaces, long Apply the glue in the form of
workpieces points
Flexible materials Apply the glue in lines
(e.g. textiles)
Remove glue residue after cooling with a blunt object. If re-
quired, glued spots can be separated again by applying heat.
 Do not use inflammable solvents for cleaning the sur-
faces to be glued. Solvent remainders can ignite from the
hot glue, or hazardous vapours can develop.
Glue remainders on clothing cannot be removed.
Glued spots can be painted.
