Application and Cabling

- 23 -
G

Technical Data and Dimension Drawings

Technical Data
Operating voltage: 230 VW, 50 Hz
Power input: 1.2 W
Output: 230 VW
Switching capacity: 4 A, 230 VW, cos f > 0.8
Switching time: 120 seconds
Operating temperature range: 0 °C (32 °F) to +40 °C (104 °F)
Protection class: IP 40
All technical data is subject to change!
- 24 -
G
flush-type housing
