Before using the NUMA Concert

Power connection
Music stand
Sustain / Expression pedal

Audio output

Headphones

Audio input

8 NUMA Concert by Studiologic®
Use the power chord supplied with the instrument to con-
nect it to the power socket. Switch the unit on by using the
power button near to the power socket.
The music stand supplied can be attached to the brackets on
the back of the unit.
Connect the sustain pedal VFP 1 supplied with the unit at the
socket which is labelled Hold.
At the socket labelled Expression, you can plug in the Studio-
logic pedal VP 25, which is available as an option.
Note: If you would like to attach other pedals, please refer to the required
specifications..
Connect the audio outputs Left and Right with the inputs of
your mixing desk or amplifier etc.
Plug in your headphone(s) at one of the headphone outputs.
You can use up to two headphones at the same time.
Volume
When you use the instrument for the first time, we recom-
mend you to turn the Volume knob on the Output section
to not more than half way between 0 and Full. While you are
playing you can adjust the volume as you choose. Adjusting
the Volume knob effects all audio and headphone outputs at
the same time.
CAUTION:
To prevent hearing damage you should – as with all audio
devices – avoid using the instrument at high volume for long
periods.
You can plug in external audio devices, such as mp3-players
for playback or MIDI sound modules, at the audio input. The
Level knob near the jack on the back of the instrument is for
adjusting the input level.
USB For data transmission via USB, connect the instrument to your
computer with a USB cable. The first time you switch it on, the
instrument will be recognized by your computer automatical-
ly and the appropriate driver will be installed by the OS (class
compliant).
