TMK 61
E n g l i s h
INTRODUCTION
With the TMK 61, beginners can take their first steps in music and professionals can use it as a full-
featured instrument for working on their own compositions.
The Piano-sized keys are Velocity Sensitive and allow you to expressively control all the nuances of
your synthesizer according to the way you play, from pianissimo to fortissimo, and everywhere in
between.
Contents:
2
- TMK 61
- External power supply 9VDC 500mA
- Instructions manual
Technical Specifications:
- Compatible with all sound cards
- 61 full size synth action keys (5 octaves C-C)
- Velocity sensitive
- 1 button for Midi Channel
- 1 button for Bank Select
- 1 button for Program Change
- 1 button for Transpose
- 1 button for MEMORY functions
- One parallel Midi Output
- Sustain pedal Jack
- 9VDC 500mA (Tip+) power adapter
- Switch ON/OFF with Led

CHANGING THE SETTINGS:

MIDI Channel button - The MIDI Channel function is used to select which MIDI channel you want
the TMK 61 to send messages on.You can select the MIDI channel number by pressing and holding
the MIDI Channel button and entering the number in the second octave/numeric entry field which
corresponds to the channel you desire. Values run from 1-16
The TMK 61 will transmit on the chosen channel when you let go of the button.
Example: If you want to transmit on MIDI Channel 8, hold down the MIDI Channel button, enter the
number 8 on the numeric entry field and let go of the MIDI Channel button. The TMK 61 keyboard
will now transmit on MIDI Channel 8.
