FITTING
If your CK3000 EVOLUTION is installed by a professional,
skip directly to the next chapter, entitled
The CK3000 EVOLUTION comprises an electronic control
unit, a microphone, a 2-key remote control and two ISO
connector plugs for the car stereo.
Electronic control unit:
Do not install the control unit near the vehicle's
heater or air conditioning unit.
Protect the unit from direct exposure to sunlight.
Avoid enclosing the unit inside the vehicle's
metal wings or panels, which could affect the
quality of the Bluetooth® link.
Microphone:
The microphone must be pointed towards the
driver and preferably fitted between the sun visor
and the rear-view mirror.
Keypad:
You are advised to fit the keypad where it can
easily be reached, preferably on a flat
surface that has first been cleaned.
Connect the mute cable to the
connector provided on the keypad.
Ensure that the red and green LEDs
light up and switch off according to
the position of the key in the ignition.
«Getting Started».
CAUTION
CK3000 EVOLUTION
Connecting the mute cable and power supply
cable:
The mute cable is fitted with black ISO
connectors.
The power supply cable is fitted with grey ISO
connectors.
Car stereo with ISO plugs:
Disconnect the car stereo's audio and power
leads.
Join the female connectors of the mute cable
and power supply cable to the car stereo.
Join the vehicle's audio and power cables to the
male connectors.
