1. Remove the extension tube handle from the sweeper power head.
2. Turn sweeper power head upside down being careful Not to accidentally turn the
unit ON.
3. Remove the transparent brush cover.
4. Push in on the locking tab of the gear box and lift gear box to remove.
5. Lift the brush bar end cap up from the slot.
6. Pull the brush bar out from the bushing and slip off the belt to remove the brush bar.
7. Insert the new brush bar by fi rst inserting the brush bar into the bushing on the end
opposite the driver belt.
8. Slip the belt over the brush bar cap.
9. Insert the brush bar into the slot.
10. Insert the gear box tabs into the tab slots and push down until it clicks into place.
11. To replace the squeegee, follow instructions above for removing the gear box and
slide the squeegee out from left to right.
BATTERY REMOVAL & DISPOSAL
NOTE: If uncertain as to how to remove your battery pack, we suggest you take
your sweeper to a reputable small appliance service technician to have this service
performed
Follow these steps when battery removal is required.
This sweeper is equipped with Ni-Cd batteries and you need to dispose of them
properly. When the batteries are no longer good for use, they must be removed from
the sweeper for disposal. Do not remove the batteries for any
reason other than disposal of them. Call your nearest recycling center for
information on the recycling and disposal of Ni-Cd batteries.WARNING:
You must never use ordinary batteries for replacement as these may leak and cause
damage. Use only batteries suited for this type of sweeper.
Removal of Battery Pack
1. Remove the extension handles and dust cup container.
2. Turn unit over so that the base is facing upwards. Be careful not to turn the unit ON.
3. Push in locking tab and lift off battery assembly.
