Power ON / OFF
Connect the power cord and signal cable of the unit.
Then, press the POWER button on the front panel to turn the unit on
[R]. The power indicator on the front panel is on and the unit is in
normal operating mode now.
To turn the unit off, press the POWER button on the front panel.
The button is set to the off position [E], and the power indicator and
eventually the unit are off. Disconnect the AC power cord from the
main outlet when the appliance is not used for a long period of time.
Input switching
To switch to the input port you want to use, press the corresponding
signal selector button on the front panel or the INPUT k or j button
on the remote control. The corresponding input status indicator will
light accordingly.
Volume adjustment
You can adjust the volume setting by using the VOLUME knob on the
front panel of the unit.
To increase the volume, turn the knob clockwise. To reduce the
volume, turn the knob counterclockwise.
You can also use the VOLUME + or – button on the remote control to
adjust the volume.
Using the VOLUME knob or VOLUME + and – buttons, set the volume
to the minimum before turning on the unit each time and then
gradually increase the volume level to prevent damage to your
loudspeakers.
8

Basic Operation

Output protection
When the output of the power amplifier is overloaded, the relay of
the protection circuit of the power amplifier will be disconnected at
once. All indicators on the panel will be on at the same time and the
volume will be turned down automatically. At this time, turn off the
unit's power and eliminate any overload cause. In about 5 minutes,
turn on the unit again to check for normal operation.
A/B SPEAKER selection
Press the [A SPEAKERS B] button on the front panel or remote control,
then choose A or B selector output. If A and B indicators on the panel
both on which means A and B speakers both have output. If A or B
indicator on the panel is on, the other speaker is off.
Mute
Press the MUTE button on the remote control to mute the sound
output from the connected loudspeaker systems. While the sound is
muted, the input status indicator for the selected input source blinks.
In mute mode, press the MUTE button on the remote control again to
return to normal playback mode.
