8.16

Portamento Control (54H)

Message Format:
n:
vv:
Receive Receipt of this message first stores the Source Note Number for the next note.When the next
Note On is received,the portamento effect is applied to the note using this Source Note Number as the
pitch start point and the Note On event key number as the end point. If there already is a note being
sounded by Source NoteNumber at this time, the new note on is not performed and the portamento
effect is applied to the pitch of the note being sounded. That is to say that legato play is performed.
8.17

Reverb Send (5BH)

Message Format:
n:
vv:
Send Sent when auto accompaniment is used.
Receive Receipt changes the reverb send of the corresponding part.
8.18

RPN (64H,65H)

Message Format:
n:
ll:
mm:
8.18.1 Pitch Bend Sensitivity
Message Format:
n:
mm:
ll:
Send Sent when Bend Range is changed.
Receive Receipt changes Bend Range.
BnH 54H vvH
MIDI Channel Number
Source Key Number
BnH 5BH vvH
MIDI Channel Number
Value
BnH 64H llH (LSB)
BnH 65H mmH (MSB)
MIDI Channel Number
LSB Value
MSB Value
BnH 64H 00H
BnH 65H 00H
BnH 06H mmH
BnH 26H llH
MIDI Channel Number
MSB Value(00H - 0CH)
LSB Value(Send:00H, Receive:Ignored)
11
