Operation/settings to be done only by the authorised dealer/specialist.
Dealer
Operation/settings to be done by the authorised dealer/specialist or user.
User
Dealer
System temperature setting
The system controls the temperature for each menu based on the
outdoor ambient temperature.
• To set or change the temperatures, make sure to contact your
nearest authorised dealer.
1 Press and hold for 5 seconds to enter the
temperature range setting mode.
(The display shows SETTING.)
2 Press or to select a menu.
3 Press to enter the menu.
4 Press or to set the desired temperature.
5 Press to confirm the setting.
• Repeat steps 2 to 5 to set other menus.
User
Checking the temperature range
1 Press and hold for 5 seconds to enter the temperature range setting mode.
2 Press
or to select a menu.
• Press to exit.
Menu
Setting of low outdoor ambient temperature.
Setting of high outdoor ambient temperature.
Setting of water outlet temperature at low outdoor ambient
temperature.
Setting of water outlet temperature at high outdoor ambient
temperature.
During HEAT mode, the water outlet
temperature is adjusted as is shown the
diagram on the right.
It is performed within the preset temperature
range.
Setting of outdoor ambient temperature to turn OFF heating
operation during HEAT mode.
Setting of outdoor ambient temperature to turn ON the backup
heater.
Setting of sanitary water tank temperature.
Display
Temperature
setting
-15 °C ~ 15 °C
-15 °C ~ 15 °C
25 °C ~ 65 °C
25 °C ~ 65 °C
<Water outlet
temperature>
5 °C ~ 35 °C
-15 °C ~ 20 °C
40 °C ~ 75 °C

Temperature setting

Display
HEAT
max. water temp.
min. water temp.
<Outdoor ambient temperature>
HEAT
HEATER
TANK
9
